PD-1600TK Electric 3-Wheeled Freight Tricycle

PD-1600TK 60v Electric 3-Wheeled Freight Tricycle Open Body Electric Bicycle Small Freight Passenger Use Cargo Tricycle Electric

Category:
Description

Electric Cargo Tricycles 04 Electric Cargo Tricycles 03 Electric Cargo Tricycles 02 Electric Cargo Tricycles 01 Electric Cargo Tricycles 05

Mdel PD-1600TK Brake System Front drum/Rear drum
Overall Dimension[mm) 3070*1180*1320 Front/Rear wheels Front 3.75-12 Rear 4.00-12
Cargo box size[mm] 1600*1100*360 Front fork 37φ
Wheel base[mm] 1995 Battery 48V60V72V 20Ah~200Ah
Wheel track{mm] 980 Charging time[H) 6~8
Curb weight[kg] 230 Rear axle 160 split rear axle
Load capacity[kg] 600 Maximum speed[Km/h] 35
Motor 48V60V 1200W60h Grade ability[%] 25-28
Controller 48V60V72V24 tube Container Capacity 55setsCKD/40HQ



Mdel PD-1600ZX Brake System Front drum/Rear drum
Overall Dimension[mm) 3070*1180*1320 Front/Rear wheels Front 3.75-12 Rear 4.00-12
Cargo box size[mm] 1600*1100*360 Front fork 37φ
Wheel base[mm] 1995 Battery 48V60V72V 20Ah~200Ah
Wheel track{mm] 980 Charging time[H) 6~8
Curb weight[kg] 250 Rear axle 160 split rear axle
Load capacity[kg] 600 Maximum speed[Km/h] 35
Motor 48V60V 1200W60h Grade ability[%] 25-28
Controller 48V60V72V24 tube Container Capacity 55setsCKD/40HQ
Shipping & Payment Terms
Shipping Method:

The 3D printer packed on pallet along with all the accessories are usually shipped by sea with a 40HQ container. Customers can either designate their own shipping forwarder or use our forwarder which we have worked with for many years. The shipping fee is on customers, but we will provide with all necessary assistance.

If you are in urgent need of the printer. Air shipment is also available, but it's costly.

Payment Terms:

We accept T/T, W/U, PayPal. 50% deposit down with the order and 50% balance before shipment.
